Vehicle specification Overall Vehicle Size (L x W x H) inch 92x57x72 in Ground Clearance (inch) 5.5 in Wheelbase (inch) 69.3 in Weight with full equipment (lbs) 837.7 lbs Front/Rear Brakes Four Disc brake Parking Brake Hand-Actuated Front Tires AT22 x 7-10 Rear Tires AT22 x 10-10 Front Suspension Dual A-Arm Rear Suspension Swingarm Dual Shocks Cargo Box Dimensions (L x W x H) inch 21.8x49.6x6.5 in Box Capacity (lbs) 441 lbs Fuel Capacity 3.1 gallon Engine specification Cooling Air & Oil Engine capacity (cc) 177.3 cc Volumetric Compression Ratio 9.6:1 Drive System Type 2WD Engine Type Single Cylinder 4-Stroke Fuel System/Battery Electronic Fuel Injection Ignition type T.C.I Start type Electric Ignition Coil ECU Horsepower 12 Transmission/Final Drive CVT F/N/R; Chain Maximum power (HP /r/min) 12hp/7000~7500RPM Maximum Torque (Nm /r/min) 13N*m/6000~6500RPM Top Speed (mile/h) 27 mile
